A New Way To Work With Evo Ii 640t V3 Enterprise Urban Scout Package
Improve your workflow with the toughest EVO II yet, enriched with new accessories and camera features to meet the demands of professionals across a broad spectrum of use cases, from firefighting to search and rescue.
With a compact design that can be deployed in seconds and easy-to-use controls, the combination of thermal and visual imaging with the EVO II 640T Enterprise is a surefire way to increase efficiency without adding to stress.
Compact, Powerful, and Ready to Deploy
Get started in seconds with the EVO II 640T’s portable design and intuitive controls. Combining thermal and visual imaging, this drone offers a straightforward solution to enhance situational awareness while minimizing operational stress.
- Portable and quick to deploy for immediate action.
- Thermal and visual imaging integration to enhance decision-making.
- User-friendly interface that simplifies operations for professionals.
Equip your team with a tool that makes critical missions faster, easier, and more efficient.
Advanced Flight Technology for Superior Performance
The EVO II Enterprise takes flight performance to the next level with its innovative power system and cutting-edge design.
- Extended flight time of up to 42 minutes ensures uninterrupted operations.
- 8-mile transmission range for long-distance communication.
- Wind resistance up to 38mph keeps the drone stable in challenging conditions.
- 360° obstacle avoidance sensors for safe navigation.
- 50MP optical camera and 16x digital zoom for detailed imagery.
Rely on the EVO II 640T to perform in even the toughest environments.
Mission Versatility
With a broad selection of accessories inclused, the EVO II Enterprise can transform from a simple tool to a multifunctional flight platform that can adapt to a variety of situations.
- Loudspeaker: Enhances on-site communication by allowing for long-distance calling and audio loops.
- Spotlight: A long-range, powerful light used during night searches.
- Strobe: Used to provide critical position indication of the aircraft.
- RTK Module (Optional Accessory): Provides centimeter-accurate positional data and reduces electromagnetic interference.
- ADS-B Receiver: Allows the operator to take evasive actions to avoid mid-air collisions by detecting manned aircraft emitting ADS-B signals nearby.
Superior Flight Performance
The drone features 360° obstacle avoidance, boasting 19 sets of sensors covering the airframe. Now you can navigate around obstacles, plan paths through terrain, and build three-dimensional maps.
You can also use the predictive target tracking. Predict the trajectory of an object moving at high speed or identify up to 64 objects at once with this eye in the sky.
Encrypted internal and external storage keeps sensitive information safe, allowing users to operate with confidence.
Real-World Applications Across Industries
The EVO II 640T V3 Urban Scout Package supports critical operations in diverse fields:
- Agriculture: Monitor crop health and optimize yields with thermal imaging.
- Search and Rescue: Locate missing persons in challenging terrains using thermal sensors and predictive tracking.
- Firefighting: Assess fire perimeters and hotspots with detailed thermal data.
- Law Enforcement: Conduct aerial surveillance and enhance public safety with secure data.
- Construction and Infrastructure: Plan and monitor projects with high-resolution imaging and obstacle detection.
Take Your Operations to New Heights
Elevate your professional capabilities with the Autel EVO II 640T V3 Enterprise Urban Scout Package. Contact DSLRPros today to discover how this advanced drone can revolutionize your mission. Click here to get in touch with our experts.
Trusted by professionals worldwide, the EVO II 640T is the ultimate tool for critical operations.
Why Partner with DSLRPros?
At DSLRPros, we deliver premium drone solutions designed to meet the unique needs of your industry.
- Custom-Built Solutions: Tailored for public safety, agriculture, and construction sectors.
- Expert Insights: Solutions backed by deep industry knowledge.
- Top-Tier Technology: High-quality drones like DJI Phantom for superior performance.
- Secure Systems: Reliable, GDPR-compliant data solutions you can trust.
- Hands-On Support: Training and tools to maximize your success.
Our experience ensures you achieve operational excellence.
Specifications
EVO II Enterprise V3 Specifications |
|
Aircraft |
|
| Takeoff Weight(Without Accessories) | EVO II Pro Enterprise：2.45 lbs (1110 g) EVO II Dual 640T Enterprise：2.51 lbs (1136.5 g) |
| Diagonal Length | 16.8 inches (427 mm) |
| Size(L*W*H) | 245*130*111mm（folded） 506*620*111mm（unfolded） |
| Max Service Ceiling Altitude | 4.3 miles (7000 m) MSL |
| Max Ascent Speed | 18 mph (8 m/s (Ludicrous) |
| Max Descent Speed | 9 mph (4 m/s) (Ludicrous) |
| Max Level Flight Speed | 45 mph (20 m/s) (Ludicrous) |
| Max angular velocity | 120°/s |
| Max tilt angle | 33° (Ludicrous) |
| Max Flight Time (no wind) | 42 min（without accessories） |
| Max Hovering Time (no wind) | 38 min（with strobe） 29 min（with spotlight） 34 min（with loudspeaker） 36 min（with RTK module） |
| Operating Temperature Range | 14℉ to 104℉ (-10℃ to 40℃) |
| Max Wind Speed Resistance | 39 - 46 mph (17-20 m/s) |
| Operating Frequency | 2.400 GHz - 2.4835 GHz； 5.725GHz - 5.850 GHz |
|
Hovering accuracy
|
When RTK is enabled and working normally: Vertical: ±0.1 m; Horizontal: ±0.1 m |
| Vertical: ±0.1 m (when the visual positioning is working normally); ±0.5 m (when GPS works normally) Horizontal: ±0.3 m (when the visual positioning is working normally); ±1.5 m (when GPS works normally) |
|
| Internal storage | 8GB |
| SD storage | max. support 256GB (UHS-3 or Class 10) |
Gimbal |
|
| Gimbal | 3-axis stabilization |
| Mechanical range | Tilt: -135° to +45°; Pan: -100° to +100° |
| Controllable rotation range | Tilt: -90° to +30°; Pan: -90° to +90° |
| Max control speed (Tilt) | 300°/s |
| Angular Vibration Range | ±0.005° |
Remote controller and image transmission |
|
| Operating frequency | 902-928MHz (FCC Only) 2.400-2.4835GHz 5.725-5.850GHz (non-Japan) 5.650-5.755GHz (Japan Only) |
| Transmission power | FCC：≤33dBm CE：≤20dBm@2.4G，≤14dBm@5.8G SRRC：≤20dBm@2.4G，≤33dBm@5.8G/5.7G |
| Max Transmission Distance (unobstructed, free of interference) | FCC：15km CE：8km |
| Display screen | 2048x1536 60fps |
| Battery | 5800mAh |
| Operating time | ~3 hours (Max. Brightness) ~4.5 hours (50% Brightness) |
| Charging time | 90 minutes |
| Internal Storage | ROM 128GB |
Sensing system |
|
| Sensing system type | Omnidirectional sensing system |
| Forward | Accurate measurement range: 0.5-18 m Effective sensing speed: <12m/s Viewing angle: Horizontal: 60°, Vertical: 80° |
| Backward | Accurate measurement range: 0.5-16 m Effective sensing speed: <12m/s Viewing angle: Horizontal: 60°, Vertical: 80° |
| Upward | Accurate measurement range: 0.5-10 m Effective sensing speed: <5m/s Viewing angle: Horizontal: 65°, Vertical: 50° |
| Downward | Accurate measurement range: 0.5-10 m Effective sensing speed: <5m/s Viewing angle: horizontal: 100°, vertical: 80° |
| Left and right | Accurate measurement range: 0.5-10 m Effective sensing speed: <5m/s Viewing angle: horizontal: 65°, vertical: 50° |
| Operating Environment | Forward, Backward and Sides: Surface with clear pattern and adequate lighting (lux > 15) Upward: Detects diffuse reflective surfaces (>20%) (walls, trees, people, etc.) Downward: Surface with clear pattern and adequate lighting (lux > 15) Detects diffuse reflective surfaces (>20%) (walls, trees, people, etc.) |
EVO II Pro Enterprise V3 visual camera |
|
| Sensor | 1 inch CMOS; 20M pixels |
| Lens | FOV: 82° 35 mm format equivalent focal length: 29 mm Aperture: f/2.8 - f/11 Focus range: 0.5 m to infinity |
| ISO range | Video: 100-44000 Photos: 100-6400 |
| Shutter speed | Photo mode: 1/8000 ~ 8s Other: 1/8000 ~ 1/frame rates |
| Zoom | 1-16x (up to 3x lossless zoom) |
| Photo mode | Single shot/Burst shooting/AEB/Time Lapse/HDR |
| Maximum photo size | 5472*3648 (3:2) 5472*3076 (16:9) 3840*2160 (16:9) |
| Image Format | JPG (default) / DNG / JPG+DNG |
| Photo mode | 5472x3076P30/P25/P24 3840x2160P60/P50/P48/P30/P25/P24 2720x1528P60/P50/P48/P30/P25/P24 1920x1080P60/P50/P48/P30/P25/P24 |
| Video format | MP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265) |
| Max bitrate | 120Mbps |
| Supported file system | FAT32/exFAT |
EVO II Dual 640T Enterprise thermal camera |
|
| Sensor | Uncooled VOx Microbolometer |
|
Lens
|
FOV H33°V26° |
| Focal length 13mm | |
| Zoom | 1-16x |
| Sensor resolution | 640*512 |
| Pixel size | 12μm |
| Wavelength range | 8 - 14μm |
| Temperature range | High gain mode: -20° to +150° Low gain mode: 0° to +550° |
| Temperature measurement accuracy | ±3℃ or ±3% of reading (whichever is greater) @Environmental temperature-20℃~60℃ |
| Accurate temperature measurement distance |
2-20 meters |
| Video resolution | 640x512@30fps |
| Video format | MOV / MP4 (Support H.264/H.265) |
| Camera resolution | Infrared mode: 640*512 Picture-in-picture mode: 1920*1080, 1280*720 |
| Photo mode | Single shot Burst shooting: 3/5 frames, 3 is the default Time Lapse:JPG: 2s/5s/7s/10s/20s/30s/60s |
| Photo format | JPG (with irg file) |
EVO II Dual 640T Enterprise V3 visual camera |
|
| Sensor | 1/2 inch CMOS; 48M effective pixels |
| Lens | FOV: 79° 35 mm format equivalent focal length: 25.6 mm Aperture: f/1.8 Focus range: 0.5 m to infinity (with auto focus) |
| ISO range | Video: 100-64000 Photos: 100-6400 |
| Shutter speed | Photo mode: 1/8000 ~ 8s Other: 1/8000 ~ 1/frame rates |
| Zoom | 1-16x (up to 4x lossless zoom) |
| Photo mode | Single shot/Burst shooting/AEB/Time Lapse/HDR imaging |
| Maximum photo size | 8192*6144（4:3） 4096*3072（4:3） 3840x2160（16:9） |
| Image Format | JPG (default) / DNG / JPG+DNG |
| Video format | MOV / MP4 |
| Video resolution | 3840x2160P60/P50/P48/P30/P25/P24 2720x1528P60/P50/P48/P30/P25/P24 1920x1080P60/P50/P48/P30/P25/P24 |
| Max bitrate | 120Mbps |
| Supported file system | FAT32/exFAT |
Accessories |
|
|
Strobe
|
Dimensions：39*72*34 mm |
| Weight：19.5 g | |
| Connections：Floating Connectors | |
| Power：Avg. 1.6W | |
| Controllable Range：5000 m | |
| Light intensity：Min 50cd；Max 486cd；Avg. 290cd | |
|
Loudspeaker
|
Dimensions：46*80*77 mm |
| Weight：98.5 g | |
| Connections：Floating Connectors | |
| Power：Max 18W | |
| Decibel：120dB @ 1m；88dB @ 60m；70dB @ 110m； | |
| Max Bitrate：36kbps | |
| Adjustable Angle Range：0°~45° | |
|
Spotlight
|
Dimensions：48.5*72*63 mm |
| Weight：77 g | |
| Connections：Floating Connectors | |
| Power：Max 35W | |
| Controllable Range：30 m | |
| Adjustable Angle Range：0°~90° | |
| Illuminance：FOV14°, Max：11lux @ 30m Straight | |
|
RTK Module
|
Dimensions：55.5*72.5*57 mm |
| Weight：59.5 g | |
| Connections：Floating Connectors | |
| Power：~ 3W | |
| RTK Positioning Precision： 1.5 cm + 1 ppm（(Vertical） 1 cm + 1 ppm（Horizontal） |
|
Battery |
|
| Capacity | 7100 mAh |
| Voltage | 11.55 V |
| Battery type | LiPo 3S |
| Energy | 82 Wh |
| Weight | 365 g |
| Charging temperature range | 5℃ to 45℃ |
| Storage temperature and humidity | -10~30℃，65±20%RH |
| Recommended storage temperature | 22-28℃ |
| Max charging power | 93W |
| Charging time | 90 minutes |
Charger |
|
| Input | 100-240 V, 50/60 Hz, 1.5A |
| Output | 13.2 V ⎓ 5 A 5V⎓3A 9V⎓2A 12V⎓1.5A |
| Voltage | 13.2±0.1V |
| Rated power | 66W |
Multi-Charger |
|
| Voltage | 13.2 V |
| Charging temperature range | 5℃ to 45℃ |
