DSLRPros Matrice 30T Industrial Fleet Package

Empower Your Missions With the DSLRPros DJI Matrice 30T Industrial Fleet Package

Built for professionals who demand precision, versatility, and durability, the DJI Matrice 30T Industrial Fleet Package is the ultimate solution for public safety, inspections, and industrial operations. Designed to perform in the toughest environments, this drone integrates advanced imaging technology with cutting-edge flight capabilities, ensuring reliable performance when it matters most.

Built to Withstand the Elements

Reliable Performance in Any Weather

Rain, snow, or extreme temperatures—this drone is built to handle it all. With an IP55 weather resistance rating, the DJI Matrice 30T operates flawlessly in harsh climates, from -20°C to 50°C. Its rugged design ensures uninterrupted functionality, no matter the conditions.

Prepared for the Unexpected

Engineered with advanced redundancy systems, the Matrice 30T is ready for any challenge. Features include:

• Backup flight control sensors and dual transmission links for operational reliability.
• ADS-B receiver to alert users of approaching crewed aircraft.
• Hot-swappable batteries for continuous missions.

When emergencies arise, this drone is your trusted partner, ensuring safety and efficiency in every operation.

Tackle unpredictable scenarios confidently with the DJI Matrice 30T, a drone that adapts seamlessly to your needs.

Advanced Imaging for Critical Data

Capture Every Detail From Above

Equipped with wide-angle, zoom, and thermal cameras, the Matrice 30T provides unmatched aerial data collection. Its laser rangefinder adds precision, making it an indispensable tool for public safety and industrial applications.

• Triple-camera setup includes wide-angle, zoom, and thermal imaging for diverse needs.
• Integrated OcuSync 3 Enterprise delivers triple-channel 1080p video transmission for real-time monitoring.
• Compact and foldable design ensures portability and quick deployment.

From surveillance to inspections, the Matrice 30T delivers the critical data you need, whenever you need it.

Optimized for Public Safety and Beyond

Navigate Confined Spaces With Ease

The compact size and quiet operation of the DJI Matrice 30T allow it to access areas larger drones cannot. Whether it’s a search and rescue mission or monitoring a sensitive situation, this drone excels in delivering real-time insights without drawing unwanted attention.

• Navigate through tight spaces for precise data collection.
• Operate discreetly in challenging situations to avoid crowd disruptions.
• Easily transportable for rapid deployment across multiple locations.

When seconds count, rely on the Matrice 30T to deliver rapid, reliable results in critical situations.

Precision Control With DJI RC Plus

Command Every Mission With Confidence

The DJI RC Plus is designed for seamless control in the most demanding environments. With a large 7-inch touchscreen and an IP54 rating, this controller offers unmatched visibility and durability. Its intuitive interface ensures mission-critical operations are executed with ease.

• 7-inch high-brightness display for clear visuals, even in direct sunlight.
• Weatherproof design for reliable performance in extreme temperatures (-20°C to 50°C).
• Simple controls for rapid deployment and precise navigation.

Empower your team with the DJI RC Plus, a controller that combines durability and functionality for mission-critical tasks.

Redefining Industry Standards: Use Cases for the DJI Matrice 30T

The DJI Matrice 30T is a versatile tool built to meet the demands of professionals across a variety of industries. Its adaptability and advanced capabilities make it a valuable asset in any mission.

• Public Safety and Emergency Response: Aid search and rescue missions, disaster management, and surveillance operations with real-time aerial data.

• Infrastructure Inspections: Inspect power lines, bridges, and buildings with precision to ensure safety and compliance.

• Industrial Operations: Conduct equipment monitoring and site surveys to maintain operational efficiency.

• Environmental Conservation: Monitor wildlife habitats, assess environmental changes, and support conservation efforts.

• Agriculture: Perform crop health assessments and field analysis to optimize yields and resource usage.

The Matrice 30T is more than a drone—it’s a comprehensive solution that transforms operations across industries, delivering exceptional results every time.

Elevate Your Operations Today

The DSLRPros DJI Matrice 30T Industrial Fleet Package combines robust design, advanced imaging, and intelligent controls to meet the demands of today’s professionals. Whether it’s public safety, industrial inspections, or environmental monitoring, this package equips you with the tools needed to succeed.

Take your missions to new heights—contact DSLRPros today to learn more.

Why Choose DSLRPros?

DSLRPros delivers customized drone solutions engineered for diverse applications.

• Customized Offerings: Purpose-built tools for your industry.
• Proven Expertise: Tailored approaches to solve complex challenges.
• Superior Drones: Advanced performance from trusted brands like DJI.
• Secure Platforms: Compliance-focused tools for data integrity.
• Ongoing Support: Training programs to ensure you succeed.

Our solutions help you soar to new levels of operational excellence.

Specifications

Aircraft

• Dimensions (unfolded, excl. propellers): 470×585×215 mm (L×W×H)
• Dimensions (folded): 365×215×195 mm (L×W×H)
• Diagonal Wheelbase: 668 mm
• Weight (incl. two batteries): 3770 ± 10 g
• Max Takeoff Weight: 4000 g
• Operation Frequency[1]: 2.4000-2.4835 GHz; 5.725-5.850 GHz
• Transmitter Power (EIRP): 2.4 GHz: <33 dBm (FCC); <20 dBm (CE/SRRC/MIC) | 5.8 GHz: <33 dBm (FCC/SRRC); <14 dBm (CE)
• Hovering Accuracy (windless or breezy): Vertical: ±0.1 m (Vision System enabled); ±0.5 m (N-mode with GPS); ±0.1 m (RTK) | Horizontal: ±0.3 m (Vision System enabled); ±1.5 m (N-mode with GPS); ±0.1 m (RTK)
• RTK Positioning Accuracy (fixed RTK enabled): 1 cm+1 ppm (horizontal) | 1.5 cm+1 ppm (vertical)
• Max Angular Velocity: Pitch: 150°/sec.; Yaw: 100°/sec.
• Max Tilt Angle: 35° (N-mode and Forward Vision System enabled: 25°)
• Max Ascent/Descent Speed: 6 m/s, 5 m/s
• Max Tilt Descent Speed: 7 m/s
• Max Horizontal Speed: 23 m/s
• Max Service Ceiling Above Sea Level (without other payload): 5,000 m (with 1671 propellers) | 7,000 m (with 1676 propellers)
• Max Wind Resistance: 15 m/s | 12 m/s during taking off and landing
• Max Hover Time [2]: 36 min
• Max Flight Time[2]: 41 min
• Motor Model: 3511
• Propeller Model: 1671 | 1676 High Altitude (not included)
• Ingress Protection Rating[3]: IP55
• GNSS: GPS+Galileo+BeiDou+GLONASS(GLONASS is supported only when RTK module is enabled)
• Operating Temperature: -20° to 50° C (-4° to 122° F)

Gimbal

•  Angular Vibration Range: ±0.01°
• Controllable Range: Pan: ±90° | Tilt: -120° to +45°
• Mechanical Range: Pan: ±105° | Tilt: -135° to +60° | Roll: ±45°

Zoom Camera

• Sensor: 1/2" CMOS, Effective pixels: 48M
• Lens: Focal length: 21-75 mm (equivalent: 113-405 mm) | Aperture: f/2.8-f/4.2 | Focus: 5 m to ∞

Wide Camera

• Sensor: 1/2" CMOS, Effective pixels: 12M
• Lens: DFOV: 84° | Focal length: 4.5 mm (equivalent: 24 mm) | Aperture: f/2.8 | Focus: 1 m to ∞

Thermal Camera

• Thermal Imager: Uncooled VOx Microbolometer
• Lens: DFOV: 64° | Focal length: 9.1 mm (equivalent: 40 mm) | Aperture: f/1.0 | Focus: 5 m to ∞
• Infrared Temperature Measurement Accuracy[4]: ±2°C or ±2% (using the larger value)

FPV Camera

• Resolution: 1920×1080
• DFOV: 161°
• Frame Rate: 30 fps

Laser Module

• Wavelength: 905 nm
• Max Laser Power: 3.5 mW
• Single Pulse Width: 6 ns
• Measurement Accuracy: ± (0.2 m + D×0.15%)D is the distance to a vertical surface
• Measuring Range: 3-1,200 m (0.5×12 m vertical surface with 20% reflectivity)

Vision Systems

• Obstacle Sensing Range: Forward: 0.6-38 m | Upward/Downward/Backward/Sideward: 0.5-33 m
• FOV: 65° (H), 50° (V)
• Operating Environment: Surfaces with clear patterns and adequate lighting (> 15 lux)

Infrared Sensing Systems

• Obstacle Sensing Range: 0.1 to 10 m
• FOV: 30°
• Operating Environment: Large, diffuse, and reflective obstacles (reflectivity >10%)

TB30 Intelligent Flight Battery

• Capacity: 5880 mAh
• Voltage: 26.1 V
• Battery Type: LiPo 6S
• Energy: 131.6 Wh
• Net Weight: Approx. 685 g
• Operating Temperature: -20° to 50° C (-4° to 122° F)
• Storage Temperature: 20° to 30° C (68° to 86° F)
• Charging Temperature: -20° to 40° C (-4° to 104° F)(When the temperature is lower than 10° C (50° F), the self-heating function will be automatically enabled. Charging in a low temperature may shorten the lifetime of the battery)
• Chemical System: LiNiMnCoO2

Auxiliary Lights

• Effective Illumination Distance: 5 m
• Illumination Type: 60 Hz, solid glow

Remote Controller

• Screen: 7.02 inch LCD touchscreen, with a resolution of 1920×1200 pixels, and high brightness of 1200 cd/m2
• Internal Battery: Type: Li-ion (6500 mAh @ 7.2 V) | Charge Type: Supports battery station or USB-C charger maximum rated power 65W (max voltage of 20V) | Charge Time: 2 hours | Chemical System: LiNiCoAIO2
• External Battery (WB37 Intelligent Battery): Capacity: 4920 mAh | Voltage: 7.6 V | Battery Type: Li-ion | Energy: 37.39 Wh | Chemical System: LiCoO2
• Operating Time[5]: Internal Battery: Approx. 3 hours 18 minInternal Battery + External Battery: Approx. 6 hours
• Ingress Protection Rating[3]: IP54
• GNSS: GPS+Galileo+BeiDou
• Operating Temperature: -20° to 50° C (-4° to 122° F)

O3 Enterprise

• Operating Frequency[1]: 2.4000-2.4835 GHz, 5.725-5.850 GHz
• Max Transmission Distance (unobstructed, free of interference): 2.4000-2.4835 GHz: 15 km (FCC); 8 km (CE/SRRC/MIC)
• Max Transmission Distance (with interference): Strong Interference (urban landscape, limited line of sight, many competing signals): 1.5-3 km (FCC/CE/SRRC/MIC) | Medium Interference (suburban landscape, open line of sight, some competing signals): 3-9 km (FCC); 3-6 km (CE/SRRC/ MIC) | Weak Interference (open landscape abundant line of sight, few competing signals): 9-15 km (FCC); 6-8 km (CE/ SRRC/MIC)
• Transmitter Power (EIRP): 2.4 GHz: <33 dBm (FCC); <20 dBm (CE/ SRRC/MIC) | 5.8 GHz: <33 dBm (FCC); <14 dBm (CE); <23 dBm (SRRC)

Wi-Fi

• Protocol: Wi-Fi 6
• Operating Frequency[1]: 2.4000-2.4835 GHz; 5.150-5.250 GHz; 5.725-5.850 GHz
• Transmitter Power (EIRP): 2.4 GHz: <26 dBm (FCC); <20 dBm (CE/ SRRC/MIC) | 5.1 GHz: <26 dBm (FCC); <23 dBm (CE/ SRRC/MIC) | 5.8 GHz: <26 dBm (FCC/SRRC); <14 dBm(CE)

Bluetooth

• Protocol: Bluetooth 5.1
• Operating Frequency: 2.4000-2.4835 GHz
• Transmitter Power (EIRP): <10 dBm

BS30 Intelligent Battery Station

• Dimensions: 353×267×148 mm
• Net Weight: 3.95 kg
• Compatible Battery Type: TB30 Intelligent Flight Battery | WB37 Intelligent Battery
• Input: 100-240 VAC, 50/60 Hz
• Output: TB30 Battery Port: 26.1 V, 8.9 A (supported up to two outputs simultaneously) | WB37 Intelligent Battery: 8.7 V, 6 A
• Output Power: 525 W
• USB-C port: Max. output power of 65 W
• USB-A port: Max. output power of 10 W (5 V, 2 A)
• Power Consumption (when not charging battery): < 8 W
• Output Power (when warming up battery): Approx. 30 W
• Operating Temperature: -20° to 40° C (-4° to 104° F)
• Ingress Protection Rating[3]: IP55 (with the cover closed properly)
• Charging Time[6]: Approx. 30 min (charging two TB30 batteries from 20%-90%) | Approx. 50 min (charging two TB30 batteries from 0%-100%)
• Protection Features: Anti-Backflow Protection | Short Circuit Protection | Over Voltage Protection | Over Current Protection | Temperature Protection

In the Box

• 2x DJI Matrice 30T + TB30*2 + DJI Care Basic
• 2x DJI Matrice 30 Case
• 12x DJI Matrice 30 Series (Part 08) TB30 Intelligent Flight Battery
• 2x DJI CrystalSky/Cendence - WB37 Intelligent Battery (4920mAh)
• 4x DJI Matrice 30 Series (Part 09) 1671 Propeller
• 2x Airdata Enterprise (1 year)
• 2x Drone Landing Pad
